30 55 77 48-inch high-definition transparent smart TV ultra-thin touch screen OLED display transparent
30 55 77 48-inch high-definition transparent smart TV ultra-thin touch screen OLED display transparent
SPECIFICATIONS
Brand Name: NONE
Color depth: 16.70 million
Content Management System: Built-in CMS, cloud-based CMS, Yes
Contrast ratio: 1500:1
High-concerned chemical: none
Installation method: Hanging/Floor Type
Installation type: Glass back, ceiling mount, column mount
Material: Alloy
Model: UD-55OL
OSD language: Multi-language support
Operating System: Android 7.1 (Windows optional)
Origin: Mainland China
Panel brand: Usenda
Perspective (horizontal/vertical): 178/178
Pixel: 2.5 mm
Protection class: other
Recommend Age: 14+
Remote Facility Management: Remote Content Management
Scope of application: indoor
Service life (hours): > = 60,000 hours
Specifications: Bar screen, digital poster, touch screen, splicing screen, pavilion vertical screen
Supplier type: Original Manufacturer, ODM, Agency, Retailer, OEM, Other
Warranty: 1 year, 3 years, 12 months
Working principle: Android, Windows
available media: Data tables, photos, EDA/CAD models., Others
brightness: 500Cd/pc
certificate: CE/CCC/FCC/ROHS/ISO9001 certification
color: custom
control method: App Control Unlock, App Based, APP Remote Control, Bluetooth, Bluetooth App, Computer, Computer Control, Mobile App, Phone Control, Phone App Control, Phone/Computer, Remote Control, Phone Control, RF Remote Control, Remote Control, RF Remote Control, Wireless Remote Control, Wifi Control, WIFI, USB, Smartphone App Control, Wireless
display function: Image, cartoon, sky map
function: custom
logo: custom
material: ABS, ABS plastic, acrylic, adhesive, all-metal construction, aluminum, aluminum die-casting, aluminum alloy, aluminum alloy, aluminum alloy frame, die-casting aluminum, aluminum casting, aluminum cabinet
operating temperature: -20 °C ~ 70 °C
pixel density: 3840,2160
pixel pitch: 0.263x0.263
place of origin: Guangdong, China
power supply: 100V~ 240V AC
purpose: Advertising, Retail, Shopping Mall, Display Cuisine, Welcome Display, Self Service Business, Showroom, Wayfinding, Airport, Subway, Elevator, Restaurant Hotel Supplies, Education Type, Medical
resolution: 1920 * 1080, 3840x2160 (full high definition)
response time: < 6 milliseconds
screen scale: 16:9
screen type: Capacitive, Resistive, Touchscreen
video format: MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
voltage: 100V-240V
transparent oled screen 55
Features of 55 inch oled display
1, OLED uses a surface light source, not glare, the spectrum is close to natural light.
2, no glare and shadow, does not cause eye fatigue.
3, no UV, does not attract mosquitoes.
4, no blue light hazard, does not damage the retina.
5, OLED atmosphere is rigid and flexible. The flexible features are more design, the panel is flexible, light and thin, and can be bent.
6, using self-illumination technology, no backlight, the same energy consumption is higher brightness.
The most notable features of OLED:
1, flexible and flexible.
2, self-illumination technology, no backlight.
3, long working temperature is close to human body problems, no need to dissipate heat.
|
Specifications
|
|
|
|
Model No.
|
UD-55OL
|
|
|
Panel size
|
55"T-OLED
|
|
|
Display area(mm)/mode
|
16:9
|
|
|
Maximum resolution
|
3840x2160/1920x1080P
|
|
|
Display color
|
16.7M
|
|
|
Pixel Pitch(mm)
|
0.4845(H)×0.4845(V)
|
|
|
Brightness (nits)
|
500cd/m2
|
|
|
Contrast
|
4000:1
|
|
|
Visual angle
|
178°/178°
|
|
|
Response time
|
5ms
|
|
|
Life(hrs)
|
>60,000(hrs)
|
|
|
Input and output
|
|
|
|
USB
|
1
|
|
|
RS232
|
1
|
|
|
H DMI
|
1
|
|
|
VGA
|
1
|
|
|
LAN
|
1
|
|
|
Audio(L/R) input
|
1
|
|
|
Audio(L/R) output
|
1
|
|
|
Speaker
|
2×10W(9 ohm)
|
|
|
Android network
|
|
|
|
Android O.S
|
Version 14/Network version
|
|
|
CPU
|
rk3688
|
|
|
Main CPU Frequency
|
8G hz
|
|
|
Memory
|
Memory
|
|
|
Operation system
|
Android14
|
|
|
Android14
|
Suport SD:8GB RAM
|
|
|
Video
|
|
|
|
Color system
|
PAL/NTSC/SECAM
|
|
|
OSD display( screen menu display)
|
|
|
|
Menu language
|
Chinese/English( Multiple Language Supported)
|
|
|
Power
|
|
|
|
Power supply
|
100-240V AC 12V/ DC
|
|
|
Maximum power consumption
|
230W
|
|
|
Standby power consumption
|
<3W
|
|
|
Temperature
|
|
|
|
Working temperature
|
-20°C~+60°C
|
|
|
Storage temperature
|
-40°C~+60°C
|
|
|
Working humidity
|
25%~85%
|
|
|
Storage humidity
|
20%~90%
|
|
|
Support signal format
|
|
|
|
Video format
|
MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
|
|
|
Audio format
|
Wave/MP3/WMA/AAC
|
|
|
Image format
|
JPEG/BMP/TIFF/PNG/GIF
|
|
|
Image resolution
|
480P/720P/1080P
|
|
Lifting Type
